Lightning Rods or Air Terminal Bases

Lightning Rods or Air Terminal Bases
Lightning rod bases are used to hold the rods in place and connect it to other lightning protection products and equipment. Bases are typically made out of copper and aluminum and are to be used with, and on, compatible materials. Lightning protection bases come in many different styles for different applications. For example, you can get adhesive type bases for systems that require no penetrations, bases with no lightning protection conductor attachments for use where a conductor is not required. Bases can also be lead coated or tinned depending on your product requirements. To place an order pleace call or fill out this Quote Form. Universal Point Base lighting rod parts Universal Point Base Bronze or aluminum stamped adhesive point base for use on flat, vertical or sloping surface. Positive single bolt tension for multi-directional cable clamping. Four mounting holes for bolts or screws.

Air terminal support tab is field adjustable for any angle as shown from 0-90 degrees, eliminating the need for swivel adaptors. Note: -Field adjustable tool part number LPT302 -Available in tinned copper (eg. LPC302L12, tinned copper, 1/2" point) -Also available pre-configured for vertical applications (eg. LPA30212V, aluminum 1/2" point, factory set for vertical applications. vertical horizontal mount point base Vertical/Horizontal Mount Point Base Bronze or aluminum cast adhesive air terminal base for use on flat, vertical or gently sloping surface. Positive single bolt tension for multi-directional cable clamping. Four mounting holes for bolts or screws, or for use with hot pitch, roofing compound or commercial adhesive on built up roof surfaces or other locations when no penetration can be made. Available for all air terminals 3/8" 1/2" and 5/8" diameter. horizontal mount point base Horizontal Mount Point Base Bronze or aluminum cast adhesive air terminal base for use on flat or gently sloping surface when no penetration may be made for anchoring. Positive single bolt tension cable clamping. For use with hot pitch, roofing compound or commercial adhesive on built-up roof surfaces or other locations.

 Available for all air terminals 3/8" 1/2" and 5/8" diameter. point base for ridged roof Point Base for Ridged Roof Strap Copper or Aluminum Point Base for use on ridged roof, sloping or flat surfaces. Compression type fingers crimp over cable for direct contact. Holes provided for optional nailing locations. Available for all air terminals 3/8" 1/2" and 5/8" diameter. Ridge/Sloping Roof Point Base ridge sloping roof point base Strap Copper or Aluminum point base for use on ridged roof, sloping or flat surfaces. Positive bolt tension cable clamping. Holes provided for optional nailing locations. Available for all points 3/8" 1/2" and 5/8" diameter. Ridge/Sloping Roof Point Base Ridge or Sloping roof point base for lightning protection Strap Copper or Aluminum point Base for use on narrow surface or roof edge. Base 8" long with holes for nails or screw anchors. Positive bolt tension cable clamping. Available for all points 3/8" 1/2" and 5/8" diameter. Vertical Mount Point Base vertical mount point base Bronze or Aluminum Cast air terminal Base for use on vertical surface with horizontal run of cable. Positive bolt tension cable clamping. Two mounting holes for bolts or screws. Available for all air terminals 3/8" 1/2" and 5/8" diameter. Vertical Mount Point Base vertical mount point base Bronze or Aluminum Cast air terminal base for use on vertical surface with horizontal run of cable. Point attachment offset 2" from surface to clear overhang of wall cap or cover. Positive bolt tension cable clamping. Two mounting holes for bolts or screws. Available for all air terminals 3/8" 1/2" and 5/8" diameter. Inline Point Base Inline Point Base Bronze or Aluminum Straight in line air terminal base of hexagon metal stock. Two set screws anchor cable tight in base. Available for all air terminals 3/8" 1/2" and 5/8" diameter. Inline Point Base inline point base Bronze or Aluminum Cast straight in line air terminal base. Compression type fingers crimp over cable for direct contact. Available for air terminal size of 3/8" diameter only.

Pipe Mount Point Base and Cable Clamp Support Pipe Mount Point Base and Cable Clamp Support Bronze or Aluminum Cast Pipe Mount air terminal base for vertical pipe or mast. Bronze bases lead dipped for use on dissimilar metals. May be used with or without cable run on pipe or will allow air terminal to stand off pipe to use type 321 air terminal to cable connector. Available for all air terminals 3/8" 1/2" and 5/8" diameter. For pipe sizes greater than 2-1/2" O.D., refer to Series 596. Cone Roof Point Base Cone Roof Point Base Bronze or Aluminum Cast air terminal base for use on cone shaped metal surface. No cable connector. Use three bolts or screws for anchoring. Available for all air terminal 3/8" 1/2" and 5/8" diameter. Horizontal Bond Point Base Horizontal Bond Point Base Bronze or Aluminum Cast air terminal base for mounting directly to horizontal structural steel surface. Eight square inches of surface contact. Available for all air terminals 3/8" 1/2" and 5/8" diameter. Vertical Point Base Vertica; Point Base Strap Copper or Aluminum Offset air terminal base for use on concealed or exposed systems. Compression type fingers crimp over cable for direct contact. Holes provided for optional nailing location. Available for all air terminals 3/8" 1/2" and 5/8" diameter. We recommend auxiliary air terminal support for air terminals. Ridge Mount Point Base Ridge Mount Point Base Bronze or Aluminum Cast air terminal base or lighting rod base for use on ridged roof, sloping or flat surfaces. May be easily formed. Compression type fingers crimp over cable for direct contact. Holes provided for nails or metal screws standard - may be drilled for masonry drive-in anchors. Available for all lighting rods or air terminals 3/8" 1/2" and 5/8" diameter. Ridge Mount Point Base Ridge Mount Point Base Bronze or Aluminum Cast air terminal or lightning rod base for use on ridged roof, sloping or flat surfaces. May be easily formed. Positive bolt tension cable clamping. Holes provided for nails or metal screws standard - may be drilled for masonry drive-in anchors. Available for all lightning rods or air terminals 3/8" 1/2" and 5/8" diameter. Sloped Roof Point Base Sloped Roof Point Base Bronze or Aluminum Cast lightning rod or air terminal base for use on ridged roof, sloping or flat surfaces. May be easily formed. Positive bolt tension cable clamping. Holes provided for nails or metal screws standard - may be drilled for masonry drive-in anchors. Available for all lightning rods or air terminals 3/8" 1/2" and 5/8" diameter. Standing Seam Point Base Standing Seam Point base Bronze or Aluminum Cast lightning rod or air terminal base for standing seam roofing systems. Bottom groove 1/2" wide by 3/4" deep to secure on seam with two set screws. Adjustable cable connector for conductor runs either parallel or perpendicular to the seam. Available for all air terminals or lightning rods 3/8", 1/2" and 5/8" diameter. Penetrating Base Penetrating Base Galvanized Steel Tripod Braces for additional support of long air terminals or lightning rods. Constructed of 1/4" mild steel with heavy section washer guides. All joints welded prior to galvanizing. Two mounting holes per leg furnished for installation. Available for all 1/2" and 5/8" diameter air terminals or lightning rods. Non-Penetrating Base Non Penetrating Base Galvanized Steel Tripod Braces for additional support of long air terminals or lightning rods on flat or gently sloping surface when no penetration may be made for anchoring. Constructed of 1/4" mild steel with heavy section washer guides. All joints welded prior to galvanizing. For use with hot pitch, roofing compound or commercial adhesive on membrane surface or other locations. Available for all 1/2" and 5/8" diameter air terminal or lightning rods. Pipe Mount Point Base Pipe Mount Point Base Bronze or Aluminum cast pipe mount point base with point coupling for horizontal pipe. Provided with cable clamp to support cable beneath pipe. Can be applied to vertical pipe with LP296 right angle point coupler. Pipe Mount Point Base Pipe Mount Point Base Bronze or aluminum cast pipe mount point base with point coupling for horizontal pipe. Can be applied to vertical pipe with LP296 right angle point coupler.
